System Design - Build and Deployment system
Work in progress. This is one of the possible solution
Requirement
We are building a system that involves repeatedly (in the order of thousands of times per day) building and deploying code to hundreds of thousands of machines spread out across 5-10 regions around the world.
Building code will involve grabbing snapshots of source code using commit SHA identifiers; beyond that, we can assume that the actual implementation details of the building action are taken care of. In other words, we don't need to worry about how we would build JavaScript code or C++ code; we just need to design the system that enables the repeated building of code.
Building code will take up to 15 minutes, it'll result in a binary file of up to 10GB, and we want to have the entire deployment process (building and deploying code to our target machines) take at most 30 minutes.
Each build will need a clear end-state (SUCCESS or FAILURE), and though we care about availability (2 to 3 nines), we don't need to optimize too much on this dimension.
More clarification:
We want to design a system that takes code, builds it into a binary (an opaque blob of data—the compiled code), and deploys the result globally in an efficient and scalable way. We don't need to worry about testing code; let's assume that's already covered.
Once code is merged into the trunk or master branch of a central code repository, engineers should be able to trigger a build and deploy that build (through a UI, which we're not designing). At that point, the code has already been reviewed and is ready to ship. So to clarify, we're not creating the system that handles code being submitted for review or being merged into a master branch—just the system that takes merged code builds it, and deploys it.
This is an internal system, but we'll want to have decent availability because many outages are resolved by rolling forward or rolling back buggy code, so this part of the infrastructure may be necessary to avoid certain terrible situations. Any build should eventually reach a SUCCESS or FAILURE state regarding failure tolerance. Once a binary has been successfully built, it should be shippable to all machines globally within 30 minutes.
Engineering teams deploy hundreds of services or web applications, thousands of times per day; building code can take up to 15 minutes; and the final binaries can reach sizes of up to 10 GB. The fact that we might be dealing with hundreds of different applications shouldn't matter though; you're just designing the build pipeline and deployment system, which are agnostic to the types of applications that are getting deployed.
you can assume that you'll be building code from commits merged into a master branch. These commits have SHA identifiers (effectively arbitrary strings) that you can use to download the code that needs to be built.
